MSI PRO A620M-E, mATX, Socket AM5, Dual Channel DDR5 6800+MHz, 1x PCIe x16 slot, 1x M.2 slot, 1x HDMI, 1x VGA, 2x USB 3.2 Gen 1, 4x USB 2.0, 7.1 HD Audio, Realtek RTL8111H Gigabit LAN, 3Y
| Chipset | AMD A620 |
| CPU podrška | AMD Ryzen 7000 Series |
| CPU podnožje | Socket AM5 |
| CPU Max. količina | 1 |
| Vrsta memorije | DDR5 SDRAM |
| Format memorije | DIMM 288-pin |
| Brzina memorije | 6800MHz(PC5-54400) |
| Max. kapacitet memorije | 96 GB |
| Količina utora | 2 |
| Provjera pogrešaka | non-ECC |
| Značajke memorije | Two DDR Channels Unbuffered Dual Rank Single Rank XMP AMD EXPO |
| Integriran | Storage Controller: Supports: Level 0, Level 1, Level 10 PCI Express 4.0 x4 (1 x M.2 (Key M)) Storage Controller: Supports: Level 0, Level 1, Level 10 SATA III-600 (4) |
| Integrirani audio | Da |
| Vrsta | Integriran |
| Chipset | Realtek ALC897 |
| Audio izlaz | 7.1 Channel Surround |
| Audio standard | HD audio |
| Integrirani LAN | Da |
| LAN Chipset | Realtek RTL8111H |
| Podržana brzina | Gigabit Ethernet/Fast Ethernet/Ethernet |
| PCI Express 4.0 x16 | 1 |
| PCI Express 3.0 x1 | 1 |
| USB 2.0 | 2 (USB 2.0 (type A)) |
| VGA | 1 (15-pin D-sub) |
| USB 3.2 Gen 1 | 4 (USB 3.2 (type A)) |
| HDMI | 1 (HDMI (Type A)) |
| LAN | 1 (RJ-45) |
| Audio izlaz | 3 (3.5-mm minijack) |
| PS/2 | 2 |
| Podržani operativni sustavi | Microsoft Windows 10 64-bit Microsoft Windows 11 64-bit |
| Kabeli | SATA Cable |
| Dodaci | I/O Shield Brzi priručnik Vijci |
| Format | Micro ATX |
| Visina (mm) | 243.8 mm |
| Širina (mm) | 211 mm |
| Brand | MSI |
